Kimplas manufactures Electrofusion fittings. Long Spigot Transition Fittings and capable of being welded and threaded are sourced from well known and reputed European sources.

Weldable Transition Fittings, supplied by Kimplas are manufactured in PE100 {Black) grades, Standard SDR 11 rated and are suitable to weld SDR 9 through SDR 21 or PN 6 through PN 16. For exact recommendations on compatibility for welding, refer Kimplas Technical Specifications Manual.

The metal pipe is made of Carbon steel and is duly zinc coated. Kimplas Weldable Transition fittings are suitable for use with Electrofusion fittings and PE80 and PE100 pipes for transition from PE to metal or metal to PE connections, both in straight as well as coil form. The Long Spigot Transition Fittings are also available with Threading.

Standards:

• Carbon Pipe Compatibility :API 5L& EN:1461
• PE Pipe Compatibility : IS:14885, ISO:4437, EN:1555-2, EN:12201-2, IS:4984, ISO:4427, DIN:8074
• Threading: IS:554,(BSPT) & NPT, ISO: 7/1
• Complies with EN:1555- Part3

Download Datasheet
